IP30 Environmental Monitoring Sensor IOT LoRa Electric Fire Monitor ISO/IEC 9001

Brand Name : TimeWave

Model Number : Electrical fire monitor(LoRa)

Certification : ISO/IEC 20000-1, ISO/IEC 27001,ISO/IEC 9001

Place of Origin : Hubei ,China

MOQ : Negotiable

Price : EXW US$ 20-80/set

Payment Terms : T/T, L/C

Supply Ability : 2000 set/week

Delivery Time : 3-5 weeks after receive the payment

Packaging Details : 20pcs/carton

Frequency band : CN470

Wireless modulation mode : LoRa modulation

Battery life : 5 years

IP protection grade : IP30

Three-phase voltage : 100~500V

Input power : AC220V 50Hz

Contact Now

TIMEWAVE Smart IOT Electrical fire monitor(LoRa)

IP30 Environmental Monitoring Sensor IOT LoRa Electric Fire Monitor ISO/IEC 9001

Product Overview
The combined electrical fire monitoring detector is based on the electrical fire monitoring system. In combination with the Internet of Things, real-time data monitored will be uploaded to the cloud platform in a timely and effective manner through new generation information technologies such as big data and cloud computing. The platform monitors, counts, analyzes and shares information on the collected data. This combined electrical fire monitoring detector mainly monitors residual current, over-current, temperature, voltage, arc, etc.
IP30 Environmental Monitoring Sensor IOT LoRa Electric Fire Monitor ISO/IEC 9001
Main parameters of the product
Monitoring equipment
 Heartbeat cycle The default is once every 10 minutes.
Temperature test range 0~150℃
Residual current 0~1000mA
three-phase voltage 100~500V
three-phase current 0~100A,3000:1 open close type transformer
Detection channel Two circuit residual current detection, three circuit temperature detection
Communication mode
 Frequency band CN470
Uplink communication mode LoRa modulation
Downlink communication mode Multi wire system
Communication protocol
 LoRaWAN
Input port
 Two residual currents/temperatures, three temperatures, one three-phase voltage channel and one three-phase current channel; 220V terminal blocks; 485 communication port.
Output port Switch output port
Empty transport distance 485 communication < 500m
Physical environment Working voltage 220V
Power consumption < 3W
Others
 Adjustment accuracy (temperature and current) 1℃,1mA
Alarm loudness Not less than 70dB at 1m
Working temperature (-10~60)℃
Operating humidity (10~93)%RH
Installation method Standard guide rail type, screw fixed installation
IP protection grade IP30

IP30 Environmental Monitoring Sensor IOT LoRa Electric Fire Monitor ISO/IEC 9001IP30 Environmental Monitoring Sensor IOT LoRa Electric Fire Monitor ISO/IEC 9001IP30 Environmental Monitoring Sensor IOT LoRa Electric Fire Monitor ISO/IEC 9001IP30 Environmental Monitoring Sensor IOT LoRa Electric Fire Monitor ISO/IEC 9001
